X15H60 nichrome table
Characteristics of nichrome Cr15Ni60
Characteristics of nichrome X15H60 (pdf)
| ALLOY | Material | Designation | DIN | UNS designation | ASTM | AMS |
|---|---|---|---|---|---|---|
| Ni60Cr15 | 2.4867 | NiCr 60 15 | 17 470/17471 | N06004 | --- | --- |
CHEMICAL COMPOSITION,(%)
| Nickel,(Ni) | Chrome,(Cr) | Iron,(Fe) | Carbon,(C) | Manganese,(Mn) | Silicon,(Si) | Copper,(Cu) | Aluminum,(Al) | Rare Earth | The rest |
|---|---|---|---|---|---|---|---|---|---|
| Min. 59.0 | 14.0 - 17.0 | Basis | Max 0.10 | Max 1.0 | 1.0-1.75 | Max 0.5 | Max 0.3 | Max 0.04 | --- |
MECHANICAL PROPERTIES AT ROOM TEMPERATURE
| Number of bends,(times) | Relative elongation, % |
|---|---|
| > 7 | > 20 |
PHYSICAL PROPERTIES AT ROOM TEMPERATURE
| Density, gr/cm³ | Hardness, HB | Tensile strength, MPa | Electrical resistance, Ohm*mm2/m | Maximum operating temperature, degree (°C) | Melting point, deg (°C) | Magnetic properties |
|---|---|---|---|---|---|---|
| 8,2 | 200-220 | 637-784 | 1.12 | 1150 | 1390 | Weakly magnetic |
LIFETIME
| Diameter 6.0mm and larger | Diameter 3.0-6.0mm | Diameter 1.5-3.0mm | Diameter 0.4-1.5mm |
|---|---|---|---|
| At T=1100 ºC | At 1050 °C | At 1050 °C | At=1050ºC |
| Over 4000 hours | Over 2000 hours | More than 2000 hours | More than 1000 hours |
OPERATION TIME
| DESCRIPTION OF THE MATÉRIEL: |
|---|
| -good resistance to oxide scale formation and thermal fatigue at temperatures above 1200ºC; -permanent electrical properties; -High heat resistance, at high temperatures. |
| MAIN APPLICATIONS: Firing and drying furnaces, high-temperature furnaces, resistance elements, heaters, industrial heaters. |
