h15yu5 - 1.4767 - alkrothal® fehralevaya Feed
International Equivalent
| Mark | Analogue | W. Nr. | Aisi Uns | En | Order |
|---|---|---|---|---|---|
| ~Х15Ю5 | 1.4767 | K92400 | Delivery from the stock, in stock |
The characteristics and properties fehrali H15YU5
Characteristics and properties fechral H15YU5 (pdf)
| ALLOY | Material | designation | DIN | UNSoboznachenie | ASTM | AMS |
|---|---|---|---|---|---|---|
| OCr15Al5 | 1.4725 | Cr15Al5 | 17470 | K 92500 | B 603−1 | --- |
CHEMICAL COMPOSITION,(%)
| Chromium, (Cr) | Aluminum, (Al) | Iron, (Fe) | Carbon, (C) | Manganese, (Mn) | Silicon, (Si) | Copper, (Cu) | Nickel, (Ni) | Titanium, (Ti) | Maks0.6 | Rare earth | Rest |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 14.5- 15.5 | 4.6−5.8 | The basis | max 0.05 | max 0.7 | Maks0.6 | --- | Maks0.6 | --- | max 0.6 | --- | Zr, 0.3 Max |
MECHANICAL PROPERTIES AT ROOM TEMPERATURE
| Kolichestvoizgibany (times) | Relative extension,% |
|---|---|
| > 5 | > 16 |
Physical properties at room temperature
| Density g / cm³ | Hardness, HB | Usilienarazryv, MPa | Udelnoeelektricheskoe resistance, Ohm * mm2 / m | Maximum rabochayatemperatura, degrees (° C) | The melting point, degree (° C) | magnetic properties |
|---|---|---|---|---|---|---|
| 7.1 | 200−260 | 637−784 | 1.30 | 850 | 1400 | magnets |
LIFETIME
| Diameter 6.0 mm and more | Diameter 3,0−6,0mm | Diameter 1,5−3,0mm | Diameter 0,4−1,5mm |
|---|---|---|---|
| At T = 850 ° C | At T = 800 ° C | At T = 700 ° C | At T = 650 ° C |
| More 3500chasov | More 1800chasov | More 1800chasov | More 900chasov |
LIFETIME
| DESCRIPTION MATRERIALA: |
|---|
| -high resistance to corrosion in air, in oxidizing environments, vacuum; |
| Main application: kiln and drying, high-temperature furnaces, resistance elements, heaters, industrial heating elements. |
