Table X27Yu7M2 ferrules from supplier Evek GmbH
Description Characteristics
ALLOY OCr27Al7Mo2
Material 1.4765
Designation Cr27Al7Mo2
DIN 17 470
UNS designation K 92 500
ASTM В 603-1
AMS ---

CHEMICAL COMPOSITION, (%)

Description Characteristics
Chrome, (Cr) 26.5- 27.8
Aluminum, (Al) 6.0-7.0 6.0-7.0
Iron, (Fe) N
Carbon, (C) Max 0.05
Manganese, (Mn) (Mn) Max 0.2
Silicon, (Si) (Si) Max 0.6
Copper, (Cu) ---
Nickel, (Ni) (Ni) Max 0.5
Titanium, (Ti) 1.8-2.2
Rare Earth ---
The rest 0.3 max

MECHANICAL PROPERTIES AT ROOM TEMPERATURE

Description Characteristic
Number of bends, (times) > 5
Relative elongation, % >10

PHYSICAL PROPERTIES AT ROOM TEMPERATURE

Description Characteristics
Density, g/cm³ 7.1
Hardness, HB 200-260
Tensile strength, MPa 686-784
Specific electrical resistance, Ohm*mm2/m 1.53
Maximum operating temperature, deg (ºС) 1400
Melting temperature, deg (ºС) 1520
Magnetic Properties Magnetic

OPERATION TIME

Description Characteristic Time
Diameter 6.0 mm or more At T=1300 °C More than 4500 hours
Diameter 3.0-6.0 mm At T=1200°C More than 2500 hours
Diameter 1.5-3.0 mm At T=1150ºC More than 2500 hours
Diameter 0.4-1.5 mm At =11 500 ºC More than 1500 hours

MATERIAL DESCRIPTION: - High corrosion resistance in air environment, in oxidizing media, in vacuum;

BASIC APPLICATIONS: Firing and drying furnaces, high-temperature furnaces, resistance elements, heaters, industrial elements.
